RAIN DETECTOR

RAIN DETECTOR

Schematic

This is the schematic of the Rain Detector


Part
Total Qty.
Description
Substitutions
R111K 1/4 W Resistor
R21680 Ohm 1/4 W Resistor
D111N4001 Silicon Diode
BZ1112V Buzzer
S11SPST Switch
SCR11C106B1 SCR106CY
SENSOR1See Notes
MISC1Board, Wire, Case, PC Board (For Sensor)
